For my final assignment last quarter in synthesis class, I had a change to learn in-depth about granular synthesis and ring modulation.

An interesting thing resulted from my experiments. That was to generate water dropping on hard surface sounds. I'm recreating this through audiotool.

To achieve faux spatial perception, I have two different pulves generating two different white noise on both left/right.

This signal is then being low-passed by a slope. The cutoff of this lowpass will determine the bandwidth of each droplets of water. So the higher the cutoff, the more noise it'd sound. Very low cutoff would sound more like birdchirps, although that requires different firing patterns of the droplets.

This signal is then being ring modulated by pure sine waves generated from the Heisenberg. Its purpose is, instead of the noise being centered around 0Hz, it is now centered around whatever frequency Heisenberg is generating, as a result of ring modulation.

Both the Heisenberg and the noise is being fired by the Matrix device. I've inputted some notes and set the mode to "Random", although later in this piece, I switch to Zigzag/ Updown/etc.

One missing piece to being closer to natural sounding water is that the note should fire at less regular intervals. This is not possible, though I hope Audiotool will have the option to generate random note starting time.

Also, to better control this faux reverb effect, the release time of the Heisenberg would determine the "tail of the reverb" effect for the water droplets and manipulate the sense of how big the space is.

Just a rough draft for tonight.

Create an account or to write a comment.

  • Could you achieve the less regular intervals with humanisation of the position on all the notes?

    • That sounds like a good idea. I'll try it at some point. Though, I might be reading your comments wrongly, but I'm looking for both randomization in pitch and note-start

    • they would still be played from the humanized start point in random order from the matrix

  • but is it w e t

  • water to frying pan back to water, to fireworks.

    Really cool!

  • Republished

    test shuffling

  • huh. Interesting.

  • sounds a little like frying sometimes too (or maybe i just hear that because i'm super hungry after work).

  • Do open and see how it works ;)

  • thanks for sharing. hope all is well with you and yours :)

    • Thanks! Hope all is well on your end as well!

  • woah this is pretty cool

    although theres no match for the real thing i still think this got pretty close

  • very well done, can't believe you accomplished this :)

  • wow

  • Insane, thanks for the explantion, its amazing how many things you can acomplish with AT

  • this is super educational, thanks :D

  • this is sooo cool

  • very cool :)
